ATB's high-efficiency solar lights not only have a clean and modern design, but are also easy to install and of uncompromising quality.
The luminaires with integrated solar panels are designed to bring light and safety to places where there is no possibility of a power supply.
Even conventional luminaires are being replaced in part to meet current requirements for climate protection and carbon neutrality.
From footpaths and cycle paths to bus stops and car parks, the intelligent control of the luminaires with integrated motion detector, brightness sensor and timer ensures the right lighting for every application.
The forward-facing version makes the solar panels even more efficient and allows the luminaire to be positioned further away from the edge of the path.
Technical specifications:
4° adjustable rotation 20W LED luminaire head
approx. 2400 lm
Colour temperature approx. 6500K (optional 3000K)
3 solar panels á 22Wp (66Wp) or 1 × 22Wp top and 2 × 31Wp rear (84 Wp)
2x 50Ah long life cycle batteries
Weight without batteries 53 kg
Battery weight 14.8 kg (2 batteries per lantern)
Operating time and sensors
Adjustable from sunset to sunrise
Adjustable operating times
Motion sensor for adjustable brightness levels
Brightness sensor to adjust brightness for snow, rain or other environmental conditions
Vandalism and maintenance:
Height of solar panels over 2.5 metres
Tempered glass solar panels
Aluminium column powder coated in standard Fabton RAL 7016
Safety lock for battery door
Access to CPU and batteries from the road side (not integrated at the top -> easy maintenance)
Each ATB lantern has a NBiOT modem and a SIM card connected to the lantern manager.
ATB Lantern Manager (LaMa)
Self-monitoring management system
Easy-to-use web interface for reading the operating status (battery charge status, warning/error messages, operating modes, statistical data)
Two-way communication allows remote adjustment of lighting and switching times
Display of locations (on a map with coloured indication of the respective operating status)
Processed data can be forwarded by e-mail
Possibility of remote maintenance and service via NB-IoT communication
SUSTAINABLE & ENERGY SAVING WITH THE POWER OF THE SUN
The features of our solar lights also make them suitable for use in biosphere reserves, nature parks or biotopes, where the protection of insects and species and the reduction of light pollution are particularly important.
