Universal heating and solar controller with internet access

The CONTROL 602 and 702 are state-of-the-art system controllers that set standards. They have been designed with a series of functions for the particularly energy-saving operation of heating and solar systems.

The standard LAN interface of CONTROL 602 and 702 allows easy remote access to your system via the Internet. Using PC browsers, tablets or iPhone / smartphone devices, the current temperatures and values ​​can be recorded, displayed in curves and changed directly. For example, the heater can be activated remotely. You can get a daily report z. B. to send the yield of your system by e-mail. Likewise, the CONTROL 602 and CONTROL 702 can send e-mails, faxes or SMS via the portal to you or your installation company in case of maintenance or fault. Thus, a simple remote diagnosis is possible and maintenance costs can be reduced. In the first year, the use of the portal is free.


Old and new boiler / spa

For existing and new boiler and heating systems, whether gas, oil, biomass or heat pump, the control is possible due to the particularly large range of functions in most cases. Many boilers can also be operated modulating.
Energy and yield measurement

Energy consumption can be measured by measuring solar yields and connecting up to three external heat meters. Thus, the savings by the solar system, the hot water consumption and the consumption of heating circuits can be easily determined. You also keep track of your costs. Depending on the use of the other functions, this function is available.
Datalogger and updates via SD card

Not only data from the system as a datalogger can be continuously recorded over many years via an SD card. In addition, it is also possible to save and load the configuration or to update the operating system.
Remote control unit TR-CONTROL-TOUCH

Optional Room Thermostat and Remote Control Unit TR-CONTROL-TOUCH With the TR-CONTROL-TOUCH, besides the normal function of a room thermostat on a touchscreen, you get the main functions and the overview of the most important operating conditions as well as the temperatures in your living room.

Possible functions (depending on version and selected functionality)

Solar:

Solar control with stratified charge logic
New: Jump start for solar pump z. B. at partial shading of the collector field
Capture of solar yield with and without volumetric flow meter
New / changed: East / West with two pumps
cooling
Two memory control
pool function
Boiler control and integration:

New: Single-stage or modulating control of the boiler (power or temperature controlled)
Solid fuel boiler regulation
Return flow increase or boiler buffering
heating circuit:

Control up to three heating circuits with the CONTROL 702
New: screed drying
Hot Water:

New: Programmable timer for 3 hot water temperatures: Lowered - Normal - Extra Comfort
Time-controlled circulation control
More functions:

Multifunctional temperature difference control
Multifunctional temperature switch
New: Holiday function allows deactivation of the auto-heating + WW automatic for a set number of days
New: The storable service telephone number of the craftsman is displayed in the event of a fault
New: Datalogger, parameter storage and update operating system via SD card
Optional: Remote control and room thermostat function by using the TR-CONTROL 2 Touch
Menu texts in four languages
